UD45+ 2-In-1 Coalescing Filter with InPass bypass - 95 CFM @ 100 PSI - 3/4'' NPT

Atlas Copco UD+ Filter Range for oil aerosol / wet dust filtration (ultimate grade, general applications)

Oil coalescence filters with patented Nautilus technology.

Compressor element lubrication and your compressor installation itself can release oil aerosols and wet dust in your air system. UD+ filters efficiently remove these contaminants to protect your equipment and your processes. These innovative filtration solutions are engineered to cost-effectively provide the best air purity and meet today’s increasingly stringent quality requirements.

UD+ 2-in-1 concept saves money and space The UD+ combines two filtration steps (DD+ and PD+) into one, a unique technology to meet the quality requirements of diverse applications and offer superior energy savings. The UD+ filter provides the same air purity as a DD+-PD+ filter train with a lower pressure drop.

· Save up to 50% in space: The 2-in-1 concept is ideal for applications where space is at a premium, reducing your environmental footprint, system complexity, and installation space.

· Save money: Install UD+ filters to enjoy significant installation and maintenance (cost) savings compared to conventional filters.

Your benefits:

• Maximum oil aerosol, wet dust and water droplet filtration and drainage - High-efficiency glass fiber Nautilus technology ensures a low pressure drop.

• Patented drainage technology - A coarse 3D-structured layer/barrier provides efficient oil drainage and prevents re-entry of oil droplets into the air stream.

• Minimal operating costs - Optimal design and filter technology allow for low pressure losses.

• Cost-saving maintenance - Ribbed housing ensures easy removal of the filter bowl. The push-in element and drain connection were designed for effortless replacement. The service indicator shows (preventive) maintenance alerts.

inPASS ™ bypass

Atlas Copco’s revolutionary built-in bypass can be used to reroute the air during filter service to ensure an uninterrupted air flow. It’s an invisible invention that will give you big investment and operational savings:

• Service your filters at any time, even during working hours.

• Secured air flow for your production during maintenance.

• Reduced maintenance time as your air system doesn’t need to be shut down.

• Eliminates the huge cost of an external piping bypass.

• Lowers the risk of leakages, resulting in lower energy costs.

Performance:

- Contaminant: oil aerosol / wet dust

- Filtration technology: wrapped

- Test method: ISO 8573-2:2018, ISO 12500-1:2007

- Max oil carry-over (mg/m3): 0.001

- ISO class 8573-1: [1:-:2]

- Element service: after 8'000 hrs or 1 year

- Precede with: water separator
