DDp7+ Rough Dry Dust filter 1 micron with InPass bypass - 14 CFM @ 100 PSI - 1/2'' NPT

DDp+ Series: Optimal dry dust filtration

DDp+ filters efficiently prevent dust, corrosion particles, micro-organisms, dirt and adsorption material from entering your compressed air stream. These innovative filtration solutions are engineered to cost-effectively provide the best air purity and meet today’s strict quality demands.

Your benefits:

• Maximum dirt, solid particle, micro-organism and rust particle removal. High-efficiency pleated glass fiber media with coarse pre-filter fleece ensure a high dust-holding capacity.

• Minimal operating costs - Optimal pleated design and filter technology allow for low pressure losses.

• Cost-saving maintenance - Ribbed housing ensures easy removal of the filter bowl. The push-in element and drain connection were designed for effortless replacement. The service indicator shows (preventive) maintenance alerts.

inPASS ™ bypass. Atlas Copco’s revolutionary built-in bypass can be used to reroute the air during filter service to ensure an uninterrupted air flow. It’s an invisible invention that will give you big investment and operational savings:

• Service your filters at any time, even during working hours.

• Secured air flow for your production during maintenance.

• Reduced maintenance time as your air system doesn’t need to be shut down.

• Eliminates the huge cost of an external piping bypass.

• Lowers the risk of leakages, resulting in lower energy costs.

Performance and certification:

- Contaminant: dry dust

- Filtration technology: pleated

- Certification: ISO 8573-4:2019, ISO 12500-3:2009

- ISO class 8573-1: [2:-:3]

- Average dry pressure drop (mbar): 50

- Element service: after 8,000 operating hours or 1 year or 350 mbar pressure drop

- Precede with: dryer
